技(ji)術參數

TECHNICAL DATA

UNIT

YPR1300L

最大(da)壓(ya)制(zhi)力

Max. pressing force

kN

13000

最(zui)大脫模力(li)

Max. ejecting force

kN

534

最大填料深度

Max. filling depth

mm

140

工(gong)作周期加壓(ya)次數

Strokes per cycle

times

2-3

液(ye)壓(ya)系統最高壓(ya)力

Max. system pressure

MPa

33

裝機功率(lv)

Installed power

kW

118

左右(you)立(li)柱間(jian)凈空

Span between columns

mm

1600

動(dong)梁工作面寬度

Useful width of plunger

mm

600

動梁最大(da)行程

Max. plunger stroke

mm

295

壓縮空氣消耗量(liang)

Air consumption

m³/h 5bar

0.25

冷卻水(shui)消耗量(liang)

Water consumption at 25℃

m³/h 25℃

18

液壓油容量

System oil capacity

L

1100

整機(ji)重(zhong)量

Weight of the press

t

38
