| 主要技術參(can)數 | TECHNICAL DATA | UNIT | YP12090 |
| 最大壓制力(li) | Max.Pressing Force | kN | 120000 |
| 最(zui)大頂出(chu)力(li) | Max.Ejecting Force | kN | 400 |
| 動梁最大行(xing)程 | Max.Plunger Stroke | mm | 220 |
| 動梁下平(ping)面與工作(zuo)臺面最小(xiao)間距 | Min.Distance between Press Plunger and Table | mm | 580 |
| 動(dong)梁(liang)下平(ping)面與工作臺面最大間距 | Max.Distance between Press Plunger and Table | mm | 800 |
| 左右立(li)柱間凈空 | Clearance between Columns | mm | 3030 |
| 動梁(liang)工作面(mian)前后寬度 | Useful Width of Plunger | mm | 1400 |
| 工(gong)作臺面前(qian)后寬度 | Width of Press Table | mm | 1620 |
| 最大填料深度(du) | Max.Filling Depth | mm | 80 |
| 空循環次數可達 | Working Cycles in idle Stroke | mm-1 | 14 |
| 周(zhou)期中加壓次(ci)數 | Strokes Per Cycle | times | 2～5 |
| 主電機功(gong)率 | Power of the Main Motor | kW | 220 |
| 系(xi)統裝(zhuang)油量 | System Oil Capacity | L | 3800 |
| 系統耗氣量(liang) | Air Consumption | m3/h | 0.5 |
| 常溫水流量 | Water Consumption at 24℃ | m3/h | 45 |
| 主機(ji)重量 | Weight of the Press Body | t | 340 |
